Description
The PJ2-4000 is a high-pressure pump specifically designed for electrical networks where a PJ4 or PJ8 would be too demanding in terms of power connection. The pump is available in both water-cooled and air-cooled versions, each equipped with a soft starter. The pump operates using an intensifier system, in which hydraulic oil pressure is converted into water pressure of up to 4,000 bar.
Driven by an 18 kW motor with a maximum hydraulic pressure of 200 bar, the PJ2-4000 is significantly more energy-efficient than the PJ4 (30 kW) and the PJ8 (75 kW). This makes it highly versatile and suitable for a wide range of applications. It pairs perfectly with the Resato waterjet tables and offers sufficient capacity to cut through most materials.
Technical specification
| PJ2-4000 | |
| Maximum capacity | 1,8 L/min |
| Maximum pressure | 4000 bar |
| Maximum power | 18 kW |
| Number of pressure boosters | 1 |
